Model No.: WNL-6000g-USB
Certification: Ce, Fcc
product status: Stock
Types of: Barcode Scanner
Scanning element type: Ccd
Color point: 32 Bit
Interface Type: Usb, Usb, Rs232
place of origin: China
Warranty period (years): 1-Year
After-sales service: Call Center And On-Line Technical Support
Private Mold: Yes
Products Status: Stock
Type: Barcode Scanner
Scan Element Type: Cmos
Colour Depth: 32 Bit
Max Paper Size: N/A
Optical Resolution: 1280 x 800 pixels
Scan Speed: 60fps
Brand Name: Winson
Place Of Origin: Guangdong, China
Warranty(Year): 1-Year
After-sales Service: Call Center And On-Line Technical Support
Color: Black, Blue+Black
Interface: USB HID KEYBOARD/USB VCP/RS232
Light Source: White Led
Aim light source: Red dot laser
Field of view: Level:42°,vertical:28°
Reading Accuracy: 1D ≥0.076mm/3mil(PCS 0.9) 2D ≥ 0.221mm/8.7mil(PCS 0.9)
Barcode Reading Distance Range: 3mil:8-18cm 13mil:5-60cm
Size: 92mm*75mm* 184mm(L*W*H)
Weight: 240g
Packaging: Customized Packing (Negotiated)
Productivity: 10000
Brand: winson
Transportation: Ocean,Land,Air,Express,Others
Place of Origin: china
Supply Ability: 100000
Certificate: ce
Port: guangzhou
view more >>Recommended by seller
Built-in 2600mAh battery, super-long standby time Qr Code Scanner Module.
With mini USB receiver, plug and play, Ergonomic design, comfortable to hold Ccd Barcode Scanner.
Support to put prefix or suffix before or after scanned data,turn on/ off buzzer, identity barcode type, add keyboard keys Barcode Scanner 360(TAB, CR&LF, etc.)
|
Interface Supported
|
RS-232/USB HID KEYBOARD/USB VCP
|
|
Input Voltage
|
DC 5V±10%
|
|
Current
|
Max:135mA
|
|
Laser
|
650nm visible laser diode
|
|
Decoding rate:
|
100 scans/second± 20 scans/second
|
|
Scanning Angle
|
Pitch angle:±35°;Skew angle:±75°;Tilt angle:±40°
|
|
Min Resolution
|
0.127/5mil（PCS 0.9）
|
|
Min .PCS value
|
〉25%UPC/EAN 13（13mil）
|
|
Language
|
Multiple Languages
|
|
Data Edition
|
Support for custom data output
|
