Choose The High Quality WINSON Long Range Reader UHF RFID Handheld PDA etc.

Model No.: WPC-5000UHF

Certification: Ce

product status: Stock

Types of: Handheld Computer

Memory Capacity: ≤ 16mb, 16 GB ROM+2 GB RAM

place of origin: China

Products Status: Stock

Operating System: Android 6.0

Processor Type: Quad-core 1.3 GHz

Style: PDA

Screen Size: 4.7-inch

Weight: 530G/710G

Brand Name: Winson

Model Number: WPC-5000UHF

Place Of Origin: Guangdong, China

Expansion Slot: Mini SD card, up to 32 GB

Display: 4.7- inch, 1280 x 720 High resolution

Touch panel: Industrial-grade Capacitive Touch Panel

Keypad: 4 front keys, 4 side keys , Power key

Notification: Vibrator alerts/LED/Audio notification

Vibration Motor: Built-in programmable vibration motor

Sealing: IP65

Bluetooth: Bluetooth 4.0

WINSON WPC-5000UHF Long Range RFID Tag Reader UHF RFID Handheld PDA

Features

1. General Purpose Scanners Faster, more stable data radio transmission

2. Barcode Scanner Usb Cable More powerful, high efficient data collection

3. 2d Handheld Barcode Scanner 4.7 inch all sight high resolution touch screen, high efficient work

4. Industrial Pda Flexible dismount/assembly drawing structure. Device, pistol grip, components can be purchased separately.

Product Description

More powerful and efficient data collection function

pda Excellent UHF RFID read/write

Equipped with high-performance UHF read and write modules, with high sensitivity antenna, read and write distances up to 10 meters, tag read rate ≥200tags/s.
Support multiple ways of data collection
Equipped with the industry's most powerful barcode scanning engine, and supports professional data automatic identification and collection methods of GPS, camera etc., helps users accurately and quickly collect on-site business data.

WINSON WPC-5000UHF Long Range RFID Tag Reader UHF RFID Handheld PDA

Product Detail

System configuration

CPU	Quad-core 1.3 GHz
Operating System	Android 6.0
Memory(ROM+RAM)	16 GB +2 GB
Expansion Slot	Micro SD card, up to 32 GB
Display	4.7-inch, 1280 x 720 high resolution
Touch Panel	Industrial-grade capacitive touch panel (supporting operation with gloves)
Camera (optional)	8 MP autofocus camera in the back side, autofocus lens, LED flash
Exit Window	Corningâ Gorillaâ glass
Keypad	4 front keys, 4 side keys, Power key (can be set as customized key)
Battery	3.8V 3600mAh / 3.7V 3300mAh lithium polymer battery(PDA) + 3.7V 5200 mAh(pistol grip)
Audio	Built-in microphone /Micro USB/Headphone connector
Notification	Vibrator alerts/LED/Audio notification
Vibration Motor	Built-in programmable vibration motor
Sensor	G-Sensor/Proximity sensor/Light sensor

Structural parameter

Dimensions (LxWxD)

PDA: 150 mm x 73.5 mm x 16 mm(head 24mm thick)

PDA + handle:175mm x 89mm x 165mm

Weight

PDA(include battery)+ pistol grip(with RFID)710g

PDA(include battery)+ pistol grip(without RFID)530g

RFID (Optional)

Frequency	902MHz-928MHz,865MHz-868MHz(Customize according to required band)
Protocol	ISO18000-6B/6C/6D(According to required band)
Antenna	4dBi circularly polarized antenna
Output power	5-30dbm adjustable
Data Capture Range	10m(depends on labels)
