Model No.: WNC-7080g
Certification: Ce
product status: Stock
Types of: Barcode Scanner
Scanning element type: Ccd, Cmos
Color point: 32 Bit
Interface Type: Usb, usb, COM, PS/2
place of origin: China
Warranty period (years): 1-Year
After-sales service: Call Center And On-Line Technical Support
Private Mold: Yes
Products Status: Stock
Type: CCD Code Scanner
Scan Element Type: Ccd
Colour Depth: 32 Bit
Max Paper Size: N/A
Optical Resolution: 2500pix
Scan Speed: 350±50 (scans/second)
Brand Name: Winson
Place Of Origin: Guangdong, China
Warranty(Year): 1-Year
After-sales Service: Call Center And On-Line Technical Support
Product Name: CCD Code Scanner
Interface: USB HID KEYBOARD/USB VCP/RS-232
Light Source: 632nm red LED
Photo sensor: CCD linear sensor
Min resolution: 0.101mm/4mil(PCS 0.9)
Min .PCS value: >30%UPC/EAN 13(13mil)
Dimensions (L*W*H): 108mm * 71mm * 185mm
Weight: 168.8g
Mechanical shock: 3m drop onto concrete surface
Packaging: Customized Packing (Negotiated) 1pcs/box, 20/50pcs/carton
Productivity: 10000
Brand: WINSON
Transportation: Ocean,Land,Air,Express
Place of Origin: CHINA
Supply Ability: 100000
Certificate: CE
Port: guangzhou
General Barcode Scanner Support to put prefix or suffix before or after scanned data,turn on/ off buzzer, identity barcode type, add keyboard keys (TAB, CR&LF, etc.)
Laser Barcode Reader Application fields:Supermarket, Retail, Warehouse,Logistic,Library, Medical etc.
Scanner Mount With mini USB receiver, plug and play, Ergonomic design, comfortable to hold.
1d Barcode Module Built-in 2600mAh battery, super-long standby time.
Product Description
|
Interface Supported
|
RS-232/USB HID KEYBOARD/USB VCP
|
|
Input Voltage
|
DC 5V±10%
|
|
Current
|
Max:135mA
|
|
Image Sensor
|
CCD Linear Sensor
|
|
Sensor Resolution
|
2500pixels
|
|
Light Source
|
632nm Red LED
|
|
Decoding rate:
|
350 scans/second±20 scans/second
|
|
Scanning Angle
|
Pitch angle:±35°;Skew angle:±75°;Tilt angle:±40°
|
