Model No.: WNI-6801g
Certification: Ce
product status: Stock
Types of: Barcode Scanner
Scanning element type: Ccd, Cmos
Color point: 32 Bit
Interface Type: Usb, usb, COM, RS-232
place of origin: China
Warranty period (years): 1-Year
After-sales service: Return And Replacement
Private Mold: Yes
Products Status: Stock
Type: Barcode Scanner
Scan Element Type: Cmos
Colour Depth: 32 Bit
Max Paper Size: N/A
Optical Resolution: 640X480 pixels
Scan Speed: 350 ±50 scans/second
Brand Name: Winson
Place Of Origin: Guangdong, China
Warranty(Year): 1-Year
After-sales Service: Call Center And On-Line Technical Support
Software development kit (SDK): NO
Product Type: QR Code Scanner
Interface: USB HID KEYBOARD/USB VCP or RS-232
Photo sensor: CMOS array sensor
Voltage requirement: DC5V±10%
Light Source: Red LED
Dimensions: 90mm*67mm*168mm
Weight: 130g
Indicator: Beeper, LED
Packaging: Customized Packing (Negotiated) 1pcs/box, 20/50pcs/carton
Productivity: 10000
Brand: winson
Transportation: Ocean,Land,Air,Express,Others
Place of Origin: china
Supply Ability: 10000
Certificate: ce
Port: guangzhou
On Counter Scanner 2.4G Wireless+Wired two Mode.
Mobile Computer Support over twenty different countries' keyboard layout.
Handheld Computer With mini USB receiver, plug and play, Ergonomic design, comfortable to hold.
|
Electrical Characteristics |
|||
|
Interface Supported |
USB HID KEYBOARD/USB VCP or RS-232 |
||
|
Input Voltage |
DC 5V |
||
|
Current |
150mA |
||
|
Performance Characteristics |
|||
|
Sensor |
640×480 CMOS |
||
|
Illumination |
White LED |
||
|
Focus |
Red LED |
||
|
Scanning Angle |
Pitch angle:+55° |
||
|
|
Skew angle:+360° |
||
|
|
Tilt angle:+55° |
||
|
Field of view |
36°(H),27°(V) |
||
|
Reading accuracy |
≥5mil |
||
|
Decode Capability |
1D:Code 128,Ean-13 ,Ean-8,UPC-E,UPC-A,ITF-25(Interleaved 2 0f 5),Code39,Code93,Codabar 2D:QR Code,Data Matrix,PDF417 |
||
|
Environmental Characteristics |
|||
|
Temperature |
operation:-20°C to 60°C |
||
|
|
storage:-40°C to 80°C |
||
|
Humidity |
operation:5%~95% (no condensation) |
||
|
Ambient light |
0~100,000LUX |
||
|
Decoding Depth of Field |
|||
|
Symbology |
Resolution |
Barcode number |
Barcode width |
|
Code128 |
13mil |
10 |
4.3x3.1cm |
|
Code39 |
5mil |
7 |
3.5x1.19cm |
|
EAN13 |
13mil |
13 |
4.5x2.69cm |
|
QR Code |
15mil |
30 |
1.9x1.85cm |
|
Data Marix |
10mil |
30 |
4.5x1.16cm |
|
PDF 417 |
6.67mil |
30 |
4.0x10.5cm |
