Model No.: Z2-670
Certification: Ce, Ce
product status: Stock
Types of: Barcode Scanner
Scanning element type: Ccd, Cmos
Color point: 32 Bit
Interface Type: Usb, Usb, Rs232
place of origin: China
Warranty period (years): 1-Year
After-sales service: Call Center And On-Line Technical Support
Private Mold: Yes
Products Status: Stock
Type: Barcode Scanner
Scan Element Type: Cmos
Colour Depth: 32 Bit
Max Paper Size: N/A
Optical Resolution: 1280*800 pix
Scan Speed: 350+-50 Scans/second
Brand Name: Winson
Place Of Origin: Guangdong, China
Warranty(Year): 1-Year
After-sales Service: Call Center And On-Line Technical Support
Software development kit (SDK): NO
Interface: RS-232/USB HID KEYBOARD/USB VCP
Light Source: 8 white LEDs
Voltage requirement: DC5V±10% ; Max 135ma
Decode Capabilities: both 1D and 2D
Scan Angle: Pitch angle:±65° Skew angle:±60° Tilt angle:±180°
Reading Accuracy: DP:1D Linear:≥3 mils 2D:≥5 mils
Dimensions: 78mm x 67mm x 54mm
Packaging: Brown Box Packing or Customized Packing (Negotiated) 1pcs/box, 20/50pcs/carton
Productivity: 100000
Brand: winson
Transportation: Ocean,Land,Air,Express,Others
Place of Origin: china
Supply Ability: 1000000
Certificate: ce
Port: guangzhou
Support secondary development -- the serial port development instruction is complete to satisfy each kind of host computer control interactive demand.
Application fields: parcel locker,supermarket locker, ticket machine, self-service vending machine, intelligent express cabinet, kiosk,locker, access control machine,self-service store, check-in machine, bank counter machine, factory assembly line,logistics, hospital,PDA,etc.
Product Description
|
Interface Supported
|
RS-232/USB HID KEYBOARD/USB VCP
|
|
Input Voltage
|
DC 5V±10%
|
|
Current
|
Max:200mA
|
|
Image Sensor
|
CMOS Array Sensor
|
|
Sensor Resolution
|
1280X800 Pixels
|
|
Light Source
|
Red LED
|
|
Scanning Angle
|
Pitch angle:±60°;Skew angle:±40°;Tilt angle:±180°
|
|
Field of View
|
60°(H),40°(V)
|
|
Min Resolution
|
1D：0.101mm/4mil（PCS 0.9）
2D：0.254mm/10mil（PCS 0.9） |
|
Min .PCS value
|
〉20% UPC/EAN 13（13mil）
|
|
Language
|
Multiple Languages
|
|
Data Edition
|
Support for custom data output
|
|
Decode Capability
|
1D： Codebar，Code128,Code39,Code39,Code93,Code11,EAN13，EAN8，GS1-Databar，GS1-128（EAN-128），Interleaved 2 of 5，Matrix 2 of 5，Industry 2 of 5，UPC-A，UPC-E，ISBN，ISSN, Code 11, MSI
2D：PDF417, Data Matrix, QR Code，Micro PDF417，Micro QR Code，Aztec Code |
|
Weight
|
75g
|
|
Indicator
|
Beeper, LED
|
