Model No.: WNC-6090g
Certification: Ce, Ce, Rohs
product status: Stock
Types of: Barcode Scanner
Scanning element type: Ccd, Cmos
Color point: 32 Bit
Interface Type: Usb, usb, COM, PS/2
place of origin: China
Warranty period (years): 1-Year
After-sales service: Call Center And On-Line Technical Support
Products Status: Stock
Type: 1D Wired Barcode Scanner
Scan Element Type: Ccd
Colour Depth: 32 Bit
Max Paper Size: N/A
Optical Resolution: 4mil
Scan Speed: 350±50 (scans/second)
Brand Name: Winson
Place Of Origin: Guangdong, China
Warranty(Year): 1-Year
After-sales Service: Call Center And On-Line Technical Support
Product Name: USB Barcode Scanner
Product Type: 1D Wired Barcode Scanner
Interface: RS-232/USB HID KEYBOARD/USB VCP
Light Source: 632nm red LED
Photo sensor: CCD linear sensor
Voltage requirement: DC5V±10%
Min resolution: 0.101mm/4mil(PCS 0.9)
Min .PCS value: >30%UPC/EAN 13(13mil)
Language: Multiple languages
Error Rate: 1/500W
Packaging: Customized Packing (Negotiated) 1pcs/box, 20/50pcs/carton
Productivity: 100000
Brand: winson
Transportation: Ocean,Land,Air,Express,Others
Place of Origin: china
Supply Ability: 100000
Certificate: ce
Port: guangzhou
1. Compatibility
Compatible with the current system used by the general public, such as Wins, Android, Mac OS, IOS, Linux, and so on Oem Scan Engine.
2. Mechanical shock
After 1.5m drop onto concrete surface, still work as usual,shockproof and Anti-broken Barcode Scanner Cable.
3. Perfect process design
Winson WNC-6090g uses imported ABS material, high quality rubber is a good buffer against impact. It applies to cashier for mobile payment and Logistics & Express Barcode Scanner Usb Cable.
4. support multiple keyboard language
USA, Germany, French, Italy, Spanish, Turkey, Belgium, Brazil Czech and so on.
|
Technical Parameters |
|
|
Electrical Characteristics |
|
|
Interface |
RS-232/USB HID KEYBOARD/USB VCP |
|
Voltage requirement |
DC5V±10% |
|
Current consumption |
Max :138mA |
|
Optical Characteristics |
|
|
Photo sensor |
CCD linear sensor |
|
Sensor Resolution |
2500Pix |
|
Light source |
632nm red LED |
|
Performance Characteristics |
|
|
Scan Rate |
350±50 (scans/second) |
|
Decode angle |
Pitch angle:±70° Skew angle::±85° Tilt angle:±45° |
|
Min resolution |
0.101mm/4mil(PCS 0.9) |
|
Min.PCS value |
>25%UPC/EAN 13(13mil) |
|
Curvature |
R≥15 mm (EAN8),R≥20 mm (EAN13) (resolution=0.26mm,PCS=0.9) |
|
Language |
Multiple languages |
|
1/500W |
|
|
Identification |
EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128, Code 93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, GS1 Databar, Code 39, Code 11, MSI-Plessey, Plessey |
|
Physical Characteristics |
|
|
Dimensions |
70mm×95mm×168mm(L x W x H) |
|
Weight |
175g |
|
Environmental Characteristics |
|
|
Temp |
-20°-65°C / -4°to 149°F((operation) ) -30°- 70°C /-22°to 158°F(storage) |
|
Humidity |
5 - 90% (operation) ) 5 - 90% (storage) |
|
Ambient Light |
Fluorescent light 4000 lx max , direct sun light 80,000 lx max ,white light 4000 lx max |
|
Shock drop test |
1.5m drop onto concrete surface |
