Model No.: WNC-5060g
Certification: Ce, Other
product status: Stock
Types of: Barcode Scanner
Scanning element type: Ccd
Color point: 32 Bit
Interface Type: Usb, usb, COM, PS/2
place of origin: China
Warranty period (years): 1-Year
After-sales service: Call Center And On-Line Technical Support
Products Status: Stock
Type: Wireless 1D Scanner
Scan Element Type: CCD Barcode Scanner
Colour Depth: 32 Bit
Max Paper Size: N/A
Optical Resolution: 1500 pix
Scan Speed: 350+50(scans/second)
Brand Name: Winson
Place Of Origin: Guangdong, China
Warranty(Year): 1-Year
After-sales Service: Call Center And On-Line Technical Support
Product Name: Wireless 1D Scanner
Product Type: 1D CCD Barcode Scanner
Photo sensor: CCD linear sensor
Communications: Wired transmission mode
Communication frequency: BT 4.0
Voltage requirement: 5VDC±10%
Print Contrast: 20%UPC/EAN 13(13mil)
Current: Max:135mA
Light Source: 632nm red LED
Dimensions: 90mm*67mm*168mm
Packaging: Customized Packing (Negotiated)
Productivity: 100000
Brand: winson
Transportation: Ocean,Land,Air,Express,Others
Place of Origin: china
Supply Ability: 1000000
Certificate: ce
Port: guangzhou
2d Cmos Barcode Scanner Application fields: parcel locker,supermarket locker, ticket machine, self-service vending machine, intelligent express cabinet, kiosk,locker, access control machine,self-service store, check-in machine, bank counter machine, factory assembly line,logistics, hospital,PDA,etc.
Fast Scanning Black White Hand held bar code reader 1D laser usb wried barcode Barcode Scanner Module
Support secondary development -- the serial port development instruction is complete to satisfy each kind of host computer control interactive demand.
With mini USB receiver, plug and play, Ergonomic design, comfortable to hold Qr Scanner Module.
|
Technical Specifications |
|||||||
|
Wireless specifications |
|||||||
|
Communication mode |
Wired transmission mode/ Wireless Read-time mode&Inventory mode/Cache mode |
||||||
|
Communication frequency |
BT 4.0(2.402 to 2.480GHz Adaptive frequency hopping) |
||||||
|
Transmission range |
≤10M(In empty area 15M) |
||||||
|
Battery capacity |
1500mAh (Lithium battery) |
||||||
|
Charge Time from Empty to Full Charge |
4.5H |
||||||
|
Scans per Battery Charge |
30,000 (1 scan per second) |
||||||
|
Memory |
100,000@13Byte barcode |
||||||
|
Electrical Characteristics |
|||||||
|
Interface Supported |
USB HID KEYBOARD |
||||||
|
Input Voltage |
DC 5V±10% |
||||||
|
Current |
Max:135mA |
||||||
|
Optical Characteristics |
|||||||
|
Image Sensor |
CCD Linear Sensor |
||||||
|
Sensor Resolution |
2500pixels |
||||||
|
Light Source |
632nm Red LED |
||||||
|
Performance Characteristics |
|||||||
|
Decoding rate: |
350 scans/second±20 scans/second |
||||||
|
Scanning Angle |
Pitch angle:±35°;Skew angle:±75°;Tilt angle:±40° |
||||||
|
Min Resolution |
0.105/4mil(PCS 0.9) |
||||||
|
Min .PCS value |
>25%UPC/EAN 13(13mil) |
||||||
|
Language |
Multiple Languages |
||||||
|
Data Edition |
Support for custom data output |
||||||
|
Decode Capability |
EAN13,EAN8,UPC A,UPC E,CODABAR(NW-7),CODE 39,CODE 93,INTERLEAVED 2OF5,STANDARD 2OF5,MATRIX 2OF5,CODE 128,EAN/UCC 128,CODE 11,CHINESE POST |
||||||
|
Physical Characteristics |
|||||||
|
Dimensions |
Scanner:90mm*67mm*168mm(L*W*H) |
||||||
|
Weight |
Scanner:160g |
||||||
|
Indicator |
Beeper, LED |
||||||
|
Environmental Characteristics |
|||||||
|
Temperature |
-20° to 65°C / -4° to 149°F(operation) /-30° to 70°C /-22° to 158°F(storage) |
||||||
|
Humidity |
5 - 90% (operation) ) 5 - 90% (storage) |
||||||
|
Ambient Light: |
Up to 80,000 lx |
||||||
|
Shock Drop Test |
1.5m drop onto concrete surface |
||||||
