Model No.: WDI2000
Certification: Ce, Other, Ce,Rohs
product status: Stock
Types of: Barcode Scanner
Scanning element type: Cmos
Color point: 32 Bit
Interface Type: Usb, usb, Other
place of origin: China
Warranty period (years): 1-Year
After-sales service: Call Center And On-Line Technical Support
Private Mold: Yes
Products Status: Stock
Type: Barcode Scanner
Scan Element Type: Cmos
Colour Depth: 32 Bit
Max Paper Size: N/A
Optical Resolution: 648*488 pix
Scan Speed: 350±50 (scans/second)
Brand Name: Winson
Place Of Origin: Guangdong, China
Warranty(Year): 1-Year
After-sales Service: Call Center And On-Line Technical Support
Software development kit (SDK): NO
Color: Black
Connector: 0.5-12P FPC
Interface: TTL-232/USB
Photo sensor: CMOS array sensor
Voltage / Current: DC 3.5V±5%; Max 135ma
Sensor resolution: 648*488 pixels
Print Contrast: >25%UPC/EAN 13(13mil)
Compatibility: Win OS/Mac OS/Linux/Android/IOS/Embedded OS
Dimensions (W X D X H): 22mm x 12mm x 17mm(0.83in x 0.47in x 0.67in)
Packaging: Customized/OEM
Productivity: 10000
Brand: WINSON
Transportation: Ocean,Land,Air,Express
Place of Origin: CHINA
Supply Ability: 10000
Port: GUANGZHOU
Support secondary development -- the serial port development instruction is complete to satisfy each kind of host computer control interactive demand.
view more >>Recommended by seller
|
Interface
|
TTL-232/USB
|
|
Interface connector
|
0.5-12P FPC
|
|
Voltage requirement
|
DC 3.3V±5%
|
|
Photo sensor
|
CMOS array sensor
|
|
Current consumption
|
Max:135mA
|
|
SENSOR RESOLUTION
|
648X488 pixels
|
|
light source
|
white LED*1
|
|
Aim light source
|
Red Bar LED
|
|
Scan Rate
|
30fps
|
|
Decode angle
|
Pitch angle:±65° Skew angle:±60° Tilt angle:±180°
|
|
Min resolution
|
1D:5mil(0.127mm)
|
|
Min.PCS value
|
〉30%UPC/EAN 13（13mil）
|
|
Field of View
|
34°(H),26°(V)
|
|
Language
|
multiple languages
|
|
Identification
|
1D：UPC/EAN,Code 128, Code 39,
Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI，GS1 Databar 2D：QR，PDF417，Data Matrix |
|
Dimensions
|
22mm x 12mm x 17mm(L*W*H)
|
|
Electrical Safety
|
UL60950-1 2nd ed, CSA C22.2 No. 60950-1 2nd ed, EN60950-1/IEC60950-1 2nd ed.
|
