Model No.: WNI-600g
Certification: Ce
product status: Stock
Types of: Barcode Scanner
Scanning element type: Ccd
Color point: 32 Bit
Interface Type: Usb, usb, COM, RS-232
place of origin: China
Warranty period (years): 1-Year
After-sales service: Call Center And On-Line Technical Support
Private Mold: Yes
Products Status: Stock
Type: Barcode Scanner
Scan Element Type: Cmos
Colour Depth: 32 Bit
Max Paper Size: N/A
Optical Resolution: 640X480 pixels
Scan Speed: 350 ±50 scans/second
Brand Name: Winson
Place Of Origin: Guangdong, China
Warranty(Year): 1-Year
After-sales Service: Call Center And On-Line Technical Support
Software development kit (SDK): NO
Color: Black
Product Style: Protable Barcode Scanner
charging interface: Type-C
Battery Capacity: 800mah
Voltage requirement: DC5V±10%
Light Source: Red LED, White LED*1
Dimensions: 85mm*37mm*25mm
Weight: 40g
Sleep time: 5min
Packaging: Customized Packing (Negotiated) 1pcs/box, 20/50pcs/carton
Productivity: 100000
Brand: winson
Transportation: Ocean,Land,Air,Express,Others
Place of Origin: china
Supply Ability: 100000
Certificate: ce
Port: guangzhou
Complete independent research and development, possessing the complete set of patent, plug and play without the need to install driver Ccd Barcode Scanner .
Wide voltage design to avoid the data can’t be transmitted due to voltage fluctuation Bar Code Scanner.
|
Technical Specifications |
|||||
|
Electrical Characteristics |
|||||
|
Interface Supported |
USB HID KEYBOARD/USB VCP or RS-232 |
||||
|
Input Voltage |
DC 5V±10% |
||||
|
Current |
<500mA |
||||
|
Optical Characteristics |
|||||
|
Image Sensor |
CMOS Array Sensor |
||||
|
Sensor Resolution |
640X480 Pixels |
||||
|
Light Source |
White LED |
||||
|
Aim Light Source |
625nm Red Bar LED |
||||
|
Performance Characteristics |
|||||
|
Scanning Angle |
Pitch angle:±50°; Skew angle:±50°; Tilt angle:±180° |
||||
|
Field of View |
45°(H),34°(V) |
||||
|
Min Resolution |
≥3mil |
||||
|
Min .PCS value |
30% UPC/EAN 13(13mil) |
||||
|
Language |
Multiple Languages |
||||
|
Data Edition |
Support for custom data output |
||||
|
Decode Capability |
1D : Code128,UCC/EAN-128,AIM128,EAN-8,EAN-13,ISBN/ISSN,UPC-E,UPC-A,Interleaved 2 of 5,ITF-6,ITF-4,Matrix 2 of 5,Industrial 2 of 5,Standard 2 of 5,Code39,Codabar,Code93,Code11,Plessey,MSI-Plessey,RSS-14,RSS-Limited,RSS-Expand so on. 2D: QR ,PDF417 ,Data Matrix |
||||
|
Physical Characteristics |
|||||
|
Dimensions |
90mm*67mm*168mm(L*W*H) |
||||
|
Weight |
120g |
||||
|
Indicator |
Beeper, LED |
||||
|
Environmental Characteristics |
|||||
|
Temperature |
-0°-40°C (operation) -10°-50°C (storage) |
||||
|
Humidity |
5 - 90% (operation) ) 5 - 90% (storage) |
||||
|
Ambient Light: |
Up to 80,000 lx |
||||
|
Shock Drop Test |
1.2m drop onto concrete surface |
||||
