Model No.: WGL-300-USB
Certification: Ce
product status: Stock
Types of: Barcode Scanner
Scanning element type: Ccd, Cmos
Color point: 32 Bit
Interface Type: Usb, usb, SCSI, IEEE 1394, COM, PS/2
place of origin: China
Warranty period (years): 1-Year
After-sales service: Call Center And On-Line Technical Support
Private Mold: Yes
Products Status: Stock
Type: fixed mount code scanner
Scan Element Type: Laser
Colour Depth: 32 Bit
Max Paper Size: N/A
Optical Resolution: 5mil
Scan Speed: 100±20(scans/second)
Brand Name: Winson
Place Of Origin: Guangdong, China
Warranty(Year): 1-Year
After-sales Service: Call Center And On-Line Technical Support
Software development kit (SDK): NO
Color: Black
Product Type: 1D fixed mount barcode scanner
Interface: USB HID KEYBOARD/USB VCP/RS-232
Min X Dimension: DC 5V±10%
Current Consumption: Max:120mA
Light Source: 650nm Visible Laser Diode
Voltage requirement: -20°to 65°C / -4°to 149°F
Min. PCS value: <25%UPC/EAN 13(13mil)
Shock drop test: 1.2m drop onto concrete surface
Environmental: RoHS
Packaging: Customized Packing (Negotiated)
Productivity: 100000
Brand: winson
Transportation: Land,Ocean,Air,Express,Others
Place of Origin: china
Supply Ability: 1000
Certificate: ce
Port: guangzhou
Barcode Engine Application fields: parcel locker,supermarket locker, ticket machine, self-service vending machine, intelligent express cabinet, kiosk,locker, access control machine,self-service store, check-in machine, bank counter machine, factory assembly line,logistics, hospital,etc.
Barcode Scanner 360 Small size,easily to integrate into any device, especially for limit space application.
2d Scanner Barcode Auto-sensing scanning saves power and time -- when the product barcode passes through the scanning window, the module wakes up to read the barcode instantly.
Oem Scan Module 30M longer receiving distance
Embedded Scanner Supporting the RS232,USB,TTL,Micro USB interface.
Product Description
|
Interface
|
RS-232/USB HID KEYBOARD/USB VCP
|
|
Voltage requirement
|
DC5V±10%
|
|
Current consumption
|
Max :250mA
|
|
Photo sensor
|
CMOS array sensor
|
|
SENSOR RESOLUTION
|
1280x800 pixels
|
|
light source
|
White LED x1
|
|
Aim light source
|
red LED bar
|
|
Decode angle
|
Rotation angle：±70°；Skew angle：±70°；Tilt angle：±180°
|
|
Field of View
|
Level：53°,vertical：33°
|
